All products
DIAPHANO LED
|
Luminaire type Suspended luminaire with transparent wing structure to facilitate soft light from the master light in middle and edge light on sides to ensure soft and glare free illumination through light guided diffuser having low THD (<10%) Philips / BAG / Fulham electronic Driver. IP 20, powder coated aluminum housing.
Applications Workstation Areas, Cabins, Receptions, Conference Rooms and Halls.
Mounting methods Suspended
Optical system
40 W Homogeneously illuminated soft light emission from a micro-prismatic anti-glare cover of translucent PMMA.
LED system Efficient state of the art LEDs, Luminous efficiency of luminaire 100 Lm/W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
RA > 90 and Tunable white available on request.
Housing / Finish Powder Coated Aluminum Body with Micro-prismatic PMMA diffuser
Electrical connection Mains connection is achieved via connection cable.
Electrical version |
Powered by integral SMPS based constant current electronic driver (Philips / BAG / Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
LYNUS BD LED
Luminaire type
System luminaire for suspended applications with LED in areas with false ceilings and low THD (<10%) Philips / BAG/ Fulham electronic Driver. IP 20, anodized aluminum housing, powder coated.
Applications
Workstation Areas, Cabins, Receptions, Halls and Architectural applications.
Mounting methods
Suspended Applications in areas with false ceilings.
Optical system
Lynus BD – Direct – Indirect light emission through cover of extruded translucent PMMA.
LED system
Efficient state of the art LEDs, (30 W + 15 W) Luminous efficiency of luminaire 110 Lm / W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
Ra > 90 and Tunable white available on request.
Housing / Finish
Powder Coated Aluminum with PMMA diffuser, available in single lengths of 600 mm to 3600 mm.
Electrical connection
Mains connection is achieved via connection cable.
Electrical version
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
LYNUS CURVI LED
|
Luminaire type Aluminum profile, rolled and seamlessly welded to yield a 55 mm wide continuous light emission for installation in plasterboard ceilings with low THD (<10%) Philips / BAG/ Fulham electronic Driver. IP 20, powder coated.
Applications Workstation Areas, Conference Rooms, Lobbies, Halls, Architectural applications.
Mounting methods Recessed Mounted, Profile with trim.
Optical system Harmonious light effect due to homogeneously illuminated light emission. Cover of opal PMMA diffuser with diffuser film for even light distribution.
LED system Efficient state of the art LEDs, Luminous efficiency of luminaire 100 Lm/W, rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
RA > 90 and Tunable white available on request.
Housing / Finish Powder Coated Aluminum Profile Housing, Opal PMMA diffuser; available in multiples of meter lengths.
Electrical connection Mains connection is achieved via connection cable.
Electrical version |
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
Lynus H
Luminaire type
Pendant luminaire with LED, IP 20. Two rows of parallel acrylic conjoined through a metal housing with low THD (<10%) Philips / BAG/ Fulham electronic Driver; “H” shape.
Applications
Decorative and Architectural applications.
Mounting methods
Suspended mounted.
Optical system
Two rows of Acrylic forming “H” shape giving all around directional light effect due to homogeneously illuminated light emission.
LED system
Efficient state of the art LEDs, Luminous efficiency of luminaire 80 Lm/W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
Ra > 90 and Tunable white available on request.
Housing / Finish
100 mm high, 2 x 12 mm acrylic conjoined in “H” shape through metal housing containing the driver.
Electrical connection
Mains connection is achieved via connection cable.
Electrical version
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
LYNUS LED
|
Luminaire type System luminaire with trim for cut out ceilings with LED and low THD (<10%) Philips / BAG/ Fulham electronic Driver. Recessed Mounted version in powder coated anodized aluminum. IP 20, powder coated.
Applications Workstation Areas, Halls, Architectural applications.
Mounting methods Recessed Mounted
Optical system Lynus 5050 R - Harmonious light effect due to homogeneously illuminated light emission. Cover of translucent PMMA diffuser.
Lynus 50100 Sky - Skylight effect due to deep recessed & homogeneously illuminated light emission. Cover of translucent PMMA diffuser.
LED system Efficient state of the art LEDs, Luminous efficiency of luminaire 110 Lm/W, (100 Lm/W for Sky Version), color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
RA > 90 and Tunable white available on request.
Housing / Finish Powder Coated Aluminum Profile Housing, Clip on BWF diffuser; available in single lengths of 600 mm to 3600 mm.
Optional: Width in range of 20 mm to 300 mm available on request.
Electrical connection Mains connection is achieved via connection cable.
Electrical version |
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
LYNUS LED C
Luminaire type
Pendant luminaire with LED and low THD (<10%) Philips / BAG/ Fulham electronic Driver. IP 20, Metal reflector in “C” shape.
Applications
Decorative and General lighting applications.
Mounting methods
Surface mounted.
Optical system
185 mm metal reflector “C” shape reflecting light effect indirectly on the work plane.
LED system
Efficient state of the art LEDs, Luminous efficiency of luminaire 50 Lm/W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
Ra > 90 and Tunable white available on request.
Housing / Finish
200 mm high, 185 mm wide “C” shape deformed metal reflector housing LEDs in an aluminum profile.
Electrical connection
Mains connection is achieved via connection cable.
Electrical version
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
Lynus LED V
|
Luminaire type Pendant luminaire with LED and low THD (<10%) Philips / BAG/ Fulham electronic Driver. IP 20, anodized profile housing in “V” shape, invertible.
Applications Decorative and General lighting applications.
Mounting methods Suspended.
Optical system PMMA diffuser on either / both sides for Direct Up / Direct Down / Direct - Indirect light effect on the work plane.
LED system Efficient state of the art LEDs, Luminous efficiency of luminaire 110 Lm/W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
Efficiency mentioned is for Downlight Component.
Ra > 90 and Tunable white available on request.
Luminaire body 110 mm high, 50 / 15 mm wide “V” shape reflector housing LEDs in an aluminum profile. Maximum Single module available of up to 3600 mm, Invertible.
Electrical connection Mains connection is achieved via connection cable.
Electrical version |
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
LYNUS LED-1
|
Luminaire type System luminaire for surface mounted or suspended applications with LED and low THD (<10%) Philips / BAG/ Fulham electronic Driver. IP 20, anodized aluminum housing, powder coated.
Applications Workstation Areas, Halls, Architectural applications.
Mounting methods Suspended / Surface mounted for Lynus 5070 / 5070 FL. / 7070.
Optical system Lynus 5070 FL – Three directional volumetric light emission. Three side cover of extruded translucent PMMA.
Lynus 5070 / 7070 - Harmonious light effect due to homogeneously illuminated light emission. Cover of clip on BWF diffuser for 5070 and cover of translucent PMMA for 7070.
LED system Efficient state of the art LEDs, Luminous efficiency of luminaire 100 Lm / W - 110 Lm/W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
Ra > 90 and Tunable white available on request.
Housing / Finish Powder Coated Aluminum with PMMA diffuser, available in single lengths of 600 mm to 3600 mm for Lynus 5070 & 7070, and 600 mm to 2400 mm for Lynus 5070 FL.
Electrical connection Mains connection is achieved via connection cable.
Electrical version |
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
LYNUS LENSLAR LED
|
Luminaire type System luminaire for suspended / cut out ceilings with LED and low THD (<10%) Philips / BAG/ Fulham electronic Driver. Housing in powder coated anodized aluminum with spot lights on either end. IP 20.
Applications Workstation Areas, Receptions, Cabins, Retail Spaces, Halls and Architectural applications.
Mounting methods Suspended / Recessed Mounted
Optical system Lynus LENSLAR - Harmonious light effect due to homogeneously illuminated light emission. Cover of translucent clip-on BWF diffuser.
LED system Efficient state of the art LEDs available in 3 W+ 20 W + 3 W Modules, Luminous efficiency of luminaire 110 Lm/W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
RA > 90 and Tunable white available on request.
Housing / Finish Powder Coated Aluminum Profile Housing, Clip on BWF diffuser; available in single lengths of 1200 mm (150+900+150).
Single lengths of 1200 mm to 3600 mm.
Electrical connection Mains connection is achieved via connection cable.
Electrical version |
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
SLENDER LED
Luminaire type
Soft Edge luminaire with end caps, Satin / micro prismatic diffuser with low THD (<10%) Philips / BAG / Fulham electronic Driver. IP 20, powder coated aluminum housing.
Available to be configured as a system with or without spacers.
Applications
Workstation Areas, Cabins, Receptions, Conference Rooms and Halls.
Mounting methods
Suspended
Optical system
30 W Homogeneously illuminated Direct – Indirect light emission from a micro-prismatic anti-glare cover of translucent PMMA.
LED system
Efficient state of the art LEDs, Luminous efficiency of luminaire 100 Lm/W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
RA > 90 and Tunable white available on request.
Housing / Finish
Powder Coated Aluminum Body with Micro-prismatic PMMA diffuser
Electrical connection
Mains connection is achieved via connection cable.
Electrical version
Powered by integral SMPS based constant current electronic driver (Philips / BAG / Fulham) with low THD, output short circuit and surge voltage protection, switchable | DAL
