Luminaire type
Pendant luminaire with LED, IP 20. Two rows of parallel acrylic conjoined through a metal housing with low THD (<10%) Philips / BAG/ Fulham electronic Driver; “H” shape.
Applications
Decorative and Architectural applications.
Mounting methods
Suspended mounted.
Optical system
Two rows of Acrylic forming “H” shape giving all around directional light effect due to homogeneously illuminated light emission.
LED system
Efficient state of the art LEDs, Luminous efficiency of luminaire 80 Lm/W, color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
Ra > 90 and Tunable white available on request.
Housing / Finish
100 mm high, 2 x 12 mm acrylic conjoined in “H” shape through metal housing containing the driver.
Electrical connection
Mains connection is achieved via connection cable.
Electrical version
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
Variants
Product Code |
Watts |
L X B |
H |
Lumen Output |
Color Temperature |
CLS-Lynus-H |
36 W |
1200 mm x 12 + 12 mm |
100 mm |
2800 |
830 | 840 | 860 |
