Luminaire type System luminaire with trim for cut out ceilings with LED and low THD (<10%) Philips / BAG/ Fulham electronic Driver. Recessed Mounted version in powder coated anodized aluminum. IP 20, powder coated.
Applications Workstation Areas, Halls, Architectural applications.
Mounting methods Recessed Mounted
Optical system Lynus 5050 R - Harmonious light effect due to homogeneously illuminated light emission. Cover of translucent PMMA diffuser.
Lynus 50100 Sky - Skylight effect due to deep recessed & homogeneously illuminated light emission. Cover of translucent PMMA diffuser.
LED system Efficient state of the art LEDs, Luminous efficiency of luminaire 110 Lm/W, (100 Lm/W for Sky Version), color rendering index Ra > 80. Service life L70 (t25 °C) = 50,000 h.
RA > 90 and Tunable white available on request.
Housing / Finish Powder Coated Aluminum Profile Housing, Clip on BWF diffuser; available in single lengths of 600 mm to 3600 mm.
Optional: Width in range of 20 mm to 300 mm available on request.
Electrical connection Mains connection is achieved via connection cable.
Electrical version |
Powered by integral SMPS based constant current electronic driver (Philips / BAG/ Fulham) with low THD, output short circuit and surge voltage protection, switchable | DALI
Variants
Product Code |
Watts |
L X B |
Height / Cut Out (For Recessed Versions) |
Lumen Output |
Color Temperature |
CLS-Lynus-5050 R |
28 W |
1200 mm x 50 mm |
1200 mm x 45 mm x 50 mm |
3080 |
830 | 840 | 860 |
CLS-Lynus-50100 – S – 28 W SKY |
28 W |
1200 mm x 50 mm |
1200 mm x 45 mm x 50 mm |
2800 |
830 | 840 | 860 |
